Extra Heavy Duty Pivot Door Hinge Set - Stainless Steel

Ideal for FRONT ENTRY DOORS

Suitable for Door Applications where a free swing pivot door is required with EXTRA HEAVY DUTY Timber doors.

Ever wondered  how those grand pivot doors work?

Easy...

1. you can use a free pivot hinge set

OR

2. you can use a self closing pivot set

What should I use?

• It depends on your situation but in most residential instances a free pivot is the best option.
• The size and weight of your door also makes a difference to the type of pivot hinge set required

Do I need to buy any other parts?

The Z-PVTH-8062 is a complete package and you will only need the door and lock of your choosing

INSTALLATION?

we would recommend installation by an experienced carpenter

MODEL NO: Z-PVTH-8062

Specifications:

• Suitable for doors weighing up to 200kg
• Ideal for doors up to 1400mm wide and 2700mm High
• This set features a needle roller bearing for smooth operation
• Stainless steel top pivot cover plate
• Stainless steel heavy duty Ball bearing bottom pivot
• Top adjustable pivot set
• Heavy duty bottom strap
• Fixing screws included

The Pivot Set is suitable for use on non-controlled timber or metal doors

What's Included:

- Bottom Ball bearing stainless steel pivot foot

- heavy duty bottom door strap

- 2 part top pivot set with adjustable bearings and needle roller bearing

- stainless steel top pivot cover plate

- all fixing screws

Don't compromise with your beautiful door using lower grade pivot hinge sets buy the Z-PVTH-8062 set now

Need a self closing option?? check out our new self closing pivot set
